Dongguan FUBAO high-precision miniature cycloidal reducer adopts the principle of cycloidal pinwheel, eliminating the planetary gear stage in the RV structure. It integrates high-strength crossed roller bearings, providing advantages such as high precision, low backlash, high rigidity, and small size.

Due to its excellent performance, it has been widely used in cutting-edge fields such as semiconductor LCD manufacturing equipment, robots, and machine tools that require precision motion control.

Below is the effective solution proposed by Dongguan FUBAO for the high-precision miniature cycloidal reducer, based on the requirements of customers in the metal processing industry.

In order to improve the surface quality and efficiency of metal workpieces, machine tools must achieve high precision, high efficiency, process hard materials, have high reliability, long lifespan, and low wear during operation. As the core component of automation equipment, how does the high-precision miniature cycloidal reducer function in machine tool processing? Below, we will explain the role of this reducer through two cases.

CASE STUDY

(Case One) B-axis rotating tool head

The high-precision miniature cycloidal reducer adopts cycloidal transmission technology to increase the transmission torque and achieve extraordinary processing accuracy. Its compact design replaces the expensive combination of bearings and harmonic reducers.

(Case Two) Lathe spindle C-axis positioning

The high-strength radial bearings, high rigidity, and low runout value of the high-precision miniature cycloidal reducer eliminate lathe shape deviations and ensure the surface quality of workpieces.

From the above cases, it can be seen that the high-precision miniature cycloidal reducer is closely related to the machining accuracy of machine tools. It can even be said that the performance of the reducer largely determines the performance of the machine tool.

So, what are the performance characteristics of the high-precision miniature cycloidal reducer that plays an important role in the machine tool processing industry?

Cycloidal Reducers play an important role in the machine tool processing

Low transmission loss and low transmission error, significantly improving the precision of machine tools.
Excellent lifespan, improving machine tool quality and lifespan to some extent.
High rigidity and low vibration characteristics, ensuring smooth and precise movement of the machine tool, improving the surface smoothness and accuracy of workpieces, and shortening machine tool processing time, truly achieving time and energy efficiency.
Output flange design reduces runout, resulting in higher precision of the machine tool.
Single-stage reduction design with smaller axial dimensions, creating a low-noise, high-accuracy, and highly integrated environment for machine tool operation.
Advantages of small size and high speed ratio mean that smaller motors can be chosen, increasing the efficiency of machine tool operation.
High output torque improves the lifespan of the machine tool.
High overload capacity gives the machine tool high impact resistance and reliability.

Therefore, the high-precision miniature cycloidal reducer has excellent performance, making it widely used in the machine tool industry and establishing its position in the automation industry.
